Alloy C276 UNS N10276 W.Nr. 2.4819

  • VIEW FULL PRODUCT LINE
  • ORDER A SAMPLE
  • N06600

Lterature

Data Sheet

Specification

  • Heat-treating muffles and retorts
  • Vacuum furnace fixtures
  • Chlorination equipment to 1000°F
  • Titanium dioxide plants

APPLICATION

  • Heat-treating muffles and retorts
  • Vacuum furnace fixtures
  • Chlorination equipment to 1000°F
  • Titanium dioxide plants

Grade: Alloy C276 UNS N10276 W.Nr. 2.4819

INCONEL alloy C-276 (UNS N10276/W.Nr. 2.4819) is known for its corrosion resistance in a wide range of aggressive media. The high molybdenum content imparts resistance to localized corrosion such as pitting. The low carbon minimizes carbide precipitation during welding to maintain resistance to intergranular attack in heat-affected zones of welded joints. It is used in chemical processing, pollution control, pulp and paper production, industrial and municipal waste treatment and the recovery of “sour” natural gas. Applications in air pollution control include stack liners, ducts, dampers, scrubbers, stack-gas re-heaters, fans and fan housings. In chemical processing, the

FORMS

Chemical Analysis

C Mn Cr Ni Mo Fe P Si Cu W
≤0.01 ≤1.0 14.5-16.5 Balance 15-17 4.0*-7.0 ≤0.04 ≤0.08 3.0-4.5
Size Range | 1/4″ – 36″ NPS (Larger sizes available upon request) Classes | 150, 3000, 6000* Weld Schedules | 10, 10s, 40, 40s, 80, 80s, 120, 160 (Custom wall thicknesses available upon request) Mechanical Brands | Victaulic, Teekay. Chrome Moly | P5, P9, P11, P22, P91 * Standards | ASTM / ASME

Far far away, behind the word mountains, far from the countries Vokalia and Consonantia, there live the blind texts. Separated they live in Bookmarksgrove right at the coast

ENiCrMo-3: Dimensions: 2.4MM , 3.2MM,  4.0MM . AWS A5.9 M:2006

ERNiCrMo-3: Dimensions: 1.6MM ,  2.4MM , 3.2MM . AWS A5.9 M:2006

Mechanical & Physical Properties

Yield0.2% Tensile Elongation Hardness Density Specific Heat
[Mpa] [Mpa] % HRBW kg/m3 J/kg•⁰C
283 690 40 85.8 8.89 427

Far far away, behind the word mountains, far from the countries Vokalia and Consonantia, there live the blind texts. Separated they live in Bookmarksgrove right at the coast

Far far away, behind the word mountains, far from the countries Vokalia and Consonantia, there live the blind texts. Separated they live in Bookmarksgrove right at the coast

Far far away, behind the word mountains, far from the countries Vokalia and Consonantia, there live the blind texts. Separated they live in Bookmarksgrove right at the coast

Dimension(s) for this product

Description

Size Range | 1/4″ – 36″ NPS (Larger sizes available upon request) Classes | 150, 3000, 6000* Weld Schedules | 10, 10s, 40, 40s, 80, 80s, 120, 160 (Custom wall thicknesses available upon request) Mechanical Brands | Victaulic, Teekay. Chrome Moly | P5, P9, P11, P22, P91 * Standards | ASTM / ASME
See Quote

Description

Size Range | 1/4″ – 36″ NPS (Larger sizes available upon request) Classes | 150, 3000, 6000* Weld Schedules | 10, 10s, 40, 40s, 80, 80s, 120, 160 (Custom wall thicknesses available upon request) Mechanical Brands | Victaulic, Teekay. Chrome Moly | P5, P9, P11, P22, P91 * Standards | ASTM / ASME
Click here

Description

Size Range | 1/4″ – 36″ NPS (Larger sizes available upon request) Classes | 150, 3000, 6000* Weld Schedules | 10, 10s, 40, 40s, 80, 80s, 120, 160 (Custom wall thicknesses available upon request) Mechanical Brands | Victaulic, Teekay. Chrome Moly | P5, P9, P11, P22, P91 * Standards | ASTM / ASME
Click here

Description

45° elbows 90° elbows Straight and reducing tees Couplings Half couplings Caps Plugs Crosses
Click here

Description

ENiCrMo-3: Dimensions: 2.4MM , 3.2MM,  4.0MM . AWS A5.9 M:2006

ERNiCrMo-3: Dimensions: 1.6MM ,  2.4MM , 3.2MM . AWS A5.9 M:2006

See Quote

Description

45° elbows 90° elbows Straight and reducing tees Couplings Half couplings Caps Plugs Crosses
Click here

Description

ENiCrMo-3: Dimensions: 2.4MM , 3.2MM,  4.0MM . AWS A5.9 M:2006

ERNiCrMo-3: Dimensions: 1.6MM ,  2.4MM , 3.2MM . AWS A5.9 M:2006

See Quote
